Technogen Enterprise, a leading manufacturer, supplier and exporter of advanced beverage packaging machinery, proudly presents its Automatic RFC Isobaric Carbonated Beverage Filling Machine for Plastic Bottles. This high-performance monoblock system is engineered to deliver precise, hygienic and high-speed filling of carbonated beverages in PET bottles. Built with a superior blend of proven mechanical design and modern automation, it offers unmatched reliability and productivity for beverage producers worldwide.
The machine is specially designed for 100 ml to 1000 ml PET bottles, integrating Rinsing, Isobaric Filling and Capping into a single compact monoblock. It is ideal for beverage manufacturers looking to achieve consistent carbonation levels, uniform filling accuracy and leak-proof sealing in plastic bottles.
With its robust construction, advanced controls and export-grade engineering, Technogen Enterprise positions this machine as a strategic solution for brands requiring a stable, high-speed RFC Isobaric Carbonated Filling Machine built to international standards. It is also recognized in the industry under terms such as High-Speed RFC Isobaric Carbonation Filling Machine, RFC Isobaric Carbonated Drink Rinser Filler Capper Machine, and RFC Isobaric Carbonation Filling & Capping Monoblock Machine.
The Automatic RFC Isobaric Carbonated Beverage Filling Machine for PET bottles is purpose-built for beverages where carbonation retention, hygiene and sealing integrity are critical. It is ideal for:
Carbonated soft drinks
Soda and aerated beverages
Flavoured sparkling beverages
Energy drinks
Functional carbonated formulations
Tonic and mixer beverages
Carbonated beverages require controlled handling during bottling. They demand:
Controlled turbulence
Zero oxygen ingression
Stable CO₂ pressure
Accurate fill levels
Reliable sealing
This machine addresses all these challenges with its precision counter-pressure isobaric filling system, supported by a stainless-steel structural frame, advanced valve engineering and synchronized rotary handling. The result is a system capable of delivering consistent output over long production cycles with minimal operator input.
Designed with long-term operational durability in mind, the monoblock uses a robust stainless-steel frame, SS304/SS316L product contact parts and hygienic construction throughout. Its layout ensures effortless cleaning, low maintenance, and safe operation.
Rotary rinsing turret with neck-handling grips
Pressurized isobaric filling bowl for carbonation stability
ULTRA mechanical isobaric valves
Star-wheel bottle transfer for smooth movement
High-speed plastic screw capping turret
Full-body guarding with safety interlocks
PLC and HMI automation with built-in diagnostics
The machine is engineered to meet the demands of continuous bottling operations while maintaining consistent performance and product quality.
The RFC Isobaric Carbonated Drink Rinser Filler Capper Machine performs three integrated operations:
Every PET bottle undergoes an internal cleaning cycle prior to filling. The rinsing section is designed for:
Neck-handling gripping system
Stainless-steel spray nozzles
Sterile water or air rinsing
Controlled inversion & drainage
“No Bottle – No Rinse” operation
This stage ensures the internal surfaces of PET bottles are free from dust or contaminants before entering the filling module.
Isobaric counter-pressure filling is essential for PET bottle carbonation lines. The machine uses:
ULTRA 2-step mechanical filling valves
CO₂ pressurization and pressure equalization
Oxygen removal through pre-evacuation
Turbulence-free long-tube filling
Controlled venting for consistent fill level
Bottle is lifted and sealed beneath the valve.
Internal air is evacuated to reduce oxygen content.
CO₂ pressurization prepares the bottle for filling.
Product flows once tank and bottle pressures match.
Foam is minimized through controlled flow and low turbulence.
Snift action releases excess pressure to achieve the correct level.
Maintains carbonation
Reduces foaming
Ensures consistent fill volume
Enhances shelf life
Preserves flavour profile
Controls headspace precisely
This results in perfectly carbonated PET bottles ready for sealing.
PET bottles require precision screw capping to ensure secure sealing. The machine uses:
High-speed rotary capping heads
Magnetic torque adjustment
Stabilized PET bottle holders
Automatic cap feeder and chute
“No Bottle – No Cap” system
This ensures leak-proof, tamper-resistant sealing in all bottle formats.
Fully automatic RFC monoblock system
Suitable for 100 ml to 1000 ml PET bottles
Stainless-steel structure with hygienic design
ULTRA isobaric filling valves for carbonation accuracy
Smooth bottle transfer using star wheels
PLC & HMI-based controls with recipe settings
CIP-ready design for efficient cleaning
Controlled CO₂ pressurization and air removal
High accuracy with minimal foaming
Safe operation with guarded enclosures
Easy format changeover
The RFC Isobaric Carbonated Filling Machine offers a high-speed, streamlined workflow with attributes such as:
Counter-pressure filling for carbonation stability
Pressurized isobaric product tank
Level control through precise venting
High-pressure rinsing
Anti-rotation bottle support at the capper
Automatic rejection of improperly capped bottles (optional)
Optional hot water spray at discharge for hygiene
This makes the model ideal for brands requiring export-grade performance.
Optimal carbonation retention
Accurate filling under all pressure conditions
Minimal manual intervention
Reduced product spillage and waste
Efficient sanitation with CIP compatibility
Fast format changeover
Long operational life and low maintenance cost
Ideal for high-speed production environments
Perfect for:
Carbonated soft drink manufacturers
PET bottle soda producers
Sparkling and flavoured beverage companies
Energy drink facilities
Tonic water & mixer brands
Contract bottling plants
Supports PET bottle sizes from 100 ml to 1000 ml.
| Parameter | Specification |
|---|---|
| Bottle Material | PET / Plastic |
| Bottle Size Range | 100 ml to 1000 ml |
| Output Capacity | 3,000 – 12,000 bottles/hour |
| Rinsing Heads | 12 / 18 / 24 / 32 |
| Filling Heads | 12 / 18 / 24 / 32 |
| Capping Heads | 6 / 8 / 10 |
| Capping Type | Plastic Screw Capping |
| Filling Technology | Isobaric Counter-Pressure Filling |
| Filling Valve | ULTRA Mechanical 2-Step |
| CO₂ Pressure Range | 0.2 – 0.3 MPa |
| Rinse Pressure | 0.4 – 0.6 MPa |
| Construction | SS304 / SS316L |
| Electrical Supply | 3-Phase, 415V, 50/60 Hz |
| Automation | PLC + HMI |
| Operation | Fully Automatic |
| Safety Features | Guard Interlocks, Sensors, Emergency Stop |
As a globally trusted manufacturer, supplier and exporter, Technogen Enterprise delivers:
Precision-engineered carbonation filling systems
Strong international presence and support
High-grade stainless steel fabrication
Fast delivery and installation support
Long-term reliability in continuous production
Customization based on bottle size, speed and layout
Competitive pricing with proven performance
Many leading beverage brands rely on Technogen Enterprise for dependable and future-ready filling technology.
Q1: Can the machine fill carbonated beverages in PET bottles?
Yes, it is designed specifically for PET bottle carbonation.
Q2: What is the bottle size range?
100 ml to 1000 ml.
Q3: What capping system is used?
Plastic screw capping.
Q4: Does the system preserve carbonation?
Yes, through isobaric counter-pressure filling.
Q5: What speeds are available?
3,000 to 12,000 bottles per hour depending on configuration.
Technogen Enterprise welcomes beverage manufacturers seeking reliability, precision and long-term value in PET bottle carbonation.
Contact us to receive a detailed quotation, technical drawing and project consultation.
